INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
179
Function
code
Name
Detailed instruction of parameters
Default
value
3: Static autotuning 2(autotune part
parameters)
P02.00
Motor type 1
0:Asynchronous motor
1:Synchronous motor
1
P03.00
Speed loop proportional
gain1
0~200.0
16.0
P03.01
Speed loop integral time1
0.000~10.000s
0.200s
P03.02
Low switching
frequency
0.00Hz~P03.05
5.00Hz
P03.03
Speed loop proportional
gain 2
0~200.0
10.0
P03.04
Speed loop integral time 2
0.000~10.000s
0.200s
P03.05
High switching
frequency
P03.02~P00.03(the Max. frequency)
10.00Hz
P03.06
Speed loop output filter
0~8( corresponds to 0~2
8
/10ms)
0
P03.07
Compensation coefficient
of electromotion slip
50%~200%
100%
P03.08
Compensation coefficient
of braking slip
50%~200%
100%
P03.09
Current loop percentage
coefficient P
0~65535
1000
P03.10
Current loop integral
coefficient 1
0~65535
1000
P03.11
Torque setting method
0:Torque control is invalid
1:Keypad setting torque(P03.12)
2:Analog AI1 setting torque
3:Analog AI2 setting torque
4:Analog AI3 setting torque
5:Pulse frequency HDI setting torque
6:Multi-step torque setting
7:MODBUS communication setting
torque
0
