INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
181
Function
code
Name
Detailed instruction of parameters
Default
value
source
sets P03.19)
1: AI1
2: AI2
3: AI3
4: HDI
5:MODBUS communication
6:PROFIBUS/CANopen communication
7:Ethernet communication
8: Reserved
P03.19
Upper braking torque
source
0
P03.20
Keypad setting of
electromotion torque
0.0~300.0%(rated current of the motor)
180.0%
P03.21
Keypad setting of braking
torque
180.0%
P03.22
Weakening coefficient in
constant power zone
0.01~2.00
1.00
P03.23
Lowest weakening point in
constant power zone
5%~50%
10%
P03.24
Max. voltage limit
0.0~120.0%
100.0%
P03.25
Pre-exciting time
0.000~10.000s
0.0s
P03.26
Weak proportional gain
0~8000
1200
P03.27
Integral gain of the weak
magnetic
0~8000
1200
P03.28
Control mode of the weak
magnetic
0x000~0x112
Ones: Control mode selection
0~2
Tens: Inducence compensation selection
0: Compensate
1: Not compensate
Hundreds: High speed control mode
0: Mode 0
1: Mode 1
0x000
P03.29
Torque control mode
0x0000~0x7111
0x0001
