INVT Goodrive 35 Series User Manual

Goodrive35 inverters Basic operation instruction
236
H1.
2. Open collector output (suitable to B1, C1 and H1)
B -
B +
A -
A +
+5V
Open collector output
Use shield cables
B
A
+5V
OV
OV
B
A
0 V
VCC
PE
PWR/+12V
COM1/COM
Z -
Z +
+5V
Z
OV
Z
3. Complementary output (suitable to B1, C1 and H1)
B -
B +
A -
A +
+5V
Use shield cables
B
A
+5V
B
A
0 V
VCC
PE
PWR/+12V
COM/COM1
Z -
Z +
+5V
Z
Z
OV
OV
OV
Note:
1. Above diagrams are given to the features of common encoder and suitable to the H1
interface.
2. The diagram of differential output is given to the H1 interface, C1 Iinterface applies
opto-isolator and H2 interface applies differential chips. The external wiring is the same as
that of H1.
3. If the external current is limited, C1and H1 interface is suitable to encoder signal and pulse
reference signal input with greater voltage.
4. Push-pull output
