INVT Goodrive 35 Series User Manual

Goodrive35 inverters Communication protocol
280
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
Fault code of the
inverter
2102H
See the fault type instruction
R
Identifying code
of the inverter
2103H
Goodrive35-----0x0110
R
Operation
frequency
3000H
0~Fmax (unit: 0.01Hz)
R
Setting
frequency
3001H
0~Fmax (unit: 0.01Hz)
R
Bus voltage
3002H
0.0~2000.0V (unit: 0.1V)
R
Output voltage
3003H
0~1200V (unit: 1V)
R
Output current
3004H
0.0~3000.0A (unit: 0.1A)
R
Rotation speed
3005H
0~65535 (unit: 1RPM)
R
Output power
3006H
-300.0~300.0% (unit: 0.1%)
R
Output torque
3007H
-250.0~250.0% (unit: 0.1%)
R
Close loop
setting
3008H
-100.0~100.0% (unit: 0.1%)
R
Close loop
feedback
3009H
-100.0~100.0% (unit: 0.1%)
R
Input IO state
300AH
000~1FF
R
Output IO state
300BH
000~1FF
R
Analog input 1
300CH
0.00~10.00V (unit: 0.01V)
R
Analog input 2
300DH
0.00~10.00V (unit: 0.01V)
R
Analog input 3
300EH
0.00~10.00V (unit: 0.01V)
R
Analog input 4
300FH
R
Read input of
high-speed pulse
1
3010H
0.00~50.00kHz (unit: 0.01Hz)
R
Read input of
high-speed pulse
2
3011H
R
Read the current
3012H
0~15
R
