INVT Goodrive 35 Series User Manual

Goodrive35 inverters Communication protocol
279
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
=0: pre-exciting disabling
Bit5:=1 DC braking enabling
=0: DC braking disabling
200AH
Virtual input terminal command , range:
0x000~0x1FF
W/R
200BH
Virtual output terminal command , range:
0x00~0x0F
W/R
200CH
Voltage setting value(special for V/F
separation)
(0~1000, 1000 corresponds to the 100.0%)
W/R
200DH
AO output setting 1
(-1000~1000, 1000 corresponds to 100.0%)
W/R
200EH
AO output setting 2
(-1000~1000, 1000 corresponds to 100.0%)
W/R
SW 1 of the
inverter
2100H
0001H:forward running
R
0002H:forward running
0003H:stop
0004H:fault
0005H: POFF state
0006H: pre-exciting state
SW 2 of the
inverter
2101H
Bit0: =0:ready for operation =1:not ready for
operation
Bi1~2:=00:motor 1 =01:motor 2
=10:motor 3 =11:motor 4
Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4:=0:pre-alarm without overload
=1:overload pre-alarm
Bit5~ Bit6: =00: keypad control =01: terminal
control
=10: communication control
R
