INVT Goodrive 35 Series User Manual

Goodrive35 inverters Appendix A
300
Bit
Name
Function selection
(-1000~1000,1000 corresponds to 100.0%)
State word (SW):
The first word of PZD response message is state word (SW) of inverter, the definition of state
word is as follows:
State Word (SW) of Goodrive35 (SW)
Bit
Name
Value
State/Description
0~7
RUN STATE BYTE
1
Forward running
2
Reverse running
3
The inverter stops
4
The inverter is in fault
5
The inverter is in POFF state
6
Pre-exciting state
8
DC VOLTAGE ESTABLISH
1
Running ready
0
The running preparation is not ready
9~10
MOTOR GROUP
FEEDBACK
0
Motor 1 feedback
1
Motor 2 feedback
2
Motor 3 feedback
3
Motor 4 no feedback
11
MOTOR TYPE FEEDBACK
1
Synchronous motor
0
Asynchronous motor
12
OVERLOAD ALARM
1
Overload pre-alarm
0
Non-overload pre-alarm
13
RUN/STOP MODE
0
Keypad control
1
Terminal control
14
2
Communication control
3
Reserved
15
HEARTBEAT FEEDBACK
1
Heartbeat feedback
0
No heartbeat feedback
Actual value (ACT):
From 2
nd
word to 12
th
of PZD task message is main set value ACT, main frequency set value
is offered by main setting signal source.
Actual value of Goodrive35
