Value
Function
Description
4
Output current (relative to the VFD)
0–Twice the VFD rated current
5
Output current (relative to motor)
0–Twice the motor rated current
6
Output voltage
0–1.5 times the VFD rated voltage
7
Output power
0–Twice the motor rated power
8
Set torque value (bipolar)
0–Twice the motor rated current. A negative
value corresponds to 0.0% by default.
9
Output torque (absolute value)
0–±(Twice the motor rated torque)
10
AI1 input
0–10V/0–20mA
11
AI2 input
0V–10V. A negative value corresponds to
0.0% by default.
12
AI3 input
0–10V/0–20mA
13
High-speed pulse HDIA input
0.00–50.00Hz
14
Value 1 set through Modbus
communication
0–1000
15
Value 2 set through Modbus
communication
0–1000
16
Value 1 set through
PROFIBUS/CANopen
communication
0–1000
17
Value 2 set through
PROFIBUS/CANopen
communication
0–1000
18
Value 1 set through Ethernet
communication
0–1000
19
Value 2 set through Ethernet
communication
0–1000
20
High-speed pulse HDIA input
0.00–50.00Hz
21
Value 1 set through PROFINET
communication
0–1000. A negative value corresponds to
0.0% by default.
22
Torque current (bipolar)
0–Three times the motor rated current. A
negative value corresponds to 0.0% by
default.
23
Exciting current
0–Three times the motor rated current. A
negative value corresponds to 0.0% by
default.
24
Set frequency (bipolar)
0–Max. output frequency. A negative value
corresponds to 0.0% by default.
25
Ramp reference frequency (bipolar)
0–Max. output frequency. A negative value
