INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-104-
Value
Function
Description
corresponds to 0.0% by default.
26
Rotational speed (bipolar)
0–Synchronous rotation speed
corresponding to max. output frequency. A
negative value corresponds to 0.0% by
default.
27
Value 2 set through PROFINET
communication
0–1000
30
Rotational speed
0–Twice the motor rated synchronous
rotation speed
31
Output torque (bipolar)
0–Twice the motor rated torque. A negative
value corresponds to 0.0% by default.
32
PID1 output
33
PID2 output
34
PID1 reference value
35
PID1 feedback value
36
PID2 reference value
37
PID2 feedback value
38–47
Reserved
Related parameter list:
Function
code
Name
Description
Default
P06.00
Reserved
Reserved
P06.14
AO1 output
0: Running frequency (0–Max. output
frequency)
1: Set frequency (0–Max. output
frequency)
2: Ramp reference frequency (0–Max.
output frequency)
3: Rotational speed (0–Speed
corresponding to max. output
frequency)
4: Output (0–Twice the inverter unit
rated current)
5: Output current (0–Twice the motor
rated current)
6: Output (0–1.5 times the inverter unit
rated voltage)
7: Output power (0–Twice the motor
0
P06.15
AO0 output
0
P06.16
Reserved
0
