Goodrive270 series VFD for fan and pump Basic operation guidelines
-110-
Value
Function
Description
previous setting.
38
Switch the running
command channel to
communication
When the function is enabled, the running command
channel is switched to communication. When the function
is disabled, the running command channel is restored to
the previous setting.
39
Pre-exciting command
When the function is enabled, motor pre-exciting is started
until the function becomes invalid.
40
Clear power consumption
quantity
After this command becomes valid, the power consumption
quantity of the VFD will be zeroed out.
41
Keep power consumption
quantity
When the function is enabled, the present operation of the
VFD does not impact the power consumption quantity.
42
Switch the setting source
of braking torque upper
limit to keypad
The torque upper limit is set through the keypad when the
command is valid.
43–55
Reserved
56
Emergency stop
57–72
Reserved
73
PID2 start
When the command is valid, PID2 starts.
74
PID2 stop
When the command is valid, PID2 stops.
75
Pause PID2 integral
When the command is valid, PID2 integral is paused.
76
Pause PID2 control
When the command is valid, PID2 control is paused.
77
Switch PID2 polarities
When the command is valid, PID2 polarity is switched.
78
Disable HVAC (only in
stopped state)
When the command is valid, HVAC is disabled (only in
stopped state).
79
Trigger fire signal
When the command is valid, fire signal is triggered.
80
Pause PID1 control
When the command is valid, PID1 control is paused.
81
Pause PID1 integral
When the command is valid, PID1 integral is paused.
82
Switch PID1 polarities
When the command is valid, PID1 polarity is switched.
83
Trigger sleep mode
When the command is valid, the sleep mode is triggered.
84
Trigger wakeup mode
When the command is valid, the wakeup mode is triggered.
85
Manual polling
When the command is valid, manual polling is enabled.
86
Pump cleaning signal
When the command is valid, pump cleaning signal is
triggered.
87
Water level upper limit of
inlet pool
When the command is valid, the water level upper limit of
inlet pool is reached.
88
Water level lower limit of
inlet pool
When the command is valid, the water level lower limit of
inlet pool is reached.
89
Water shortage level of
When the command is valid, the water shortage level of
