INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-112-
Function
code
Name
Description
Default
P05.04
Function of S4
3: Three-wire running control
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease
setting
13: Switch between A setting and B setting
14: Switch between combination setting and A
setting
15: Switch between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Pause multi-step speed running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
23: Simple PLC stop reset
24: Pause simple PLC
25: Pause PID control
26: Pause wobbling frequency
27: Reset wobbling frequency
28: Counter reset
29: Switch between speed control and torque
control
30: Disable ACC/DEC
31: Trigger the counter
32: Reserved
33: Clear the frequency increase/decrease
setting temporarily
34: DC braking
35: Switch from motor 1 to motor 2
0
P05.05
Function of HDIA
0
P05.06
Reserved
P05.07
Reserved
