Goodrive270 series VFD for fan and pump Basic operation guidelines
-118-
Value
Function
Description
64
Control variable-frequency
circulation motor H
Related parameter list:
Function
code
Name
Description
Default
P06.00
Reserved
Reserved
P06.01
Y1 output
0: Invalid
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for running
13: Pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Set counting value reached
19: Designated counting value reached
20: External fault is valid
21: Reserved
22: Running time reached
23: Modbus communication virtual terminal
output
24: PROFIBUS/CANopen communication
virtual terminal output
25: Ethernet communication virtual terminal
output
26: DC bus voltage established
27: Z pulse output
28: Superposing pulses
0
P06.02
Reserved
P06.03
RO1 output
1
P06.04
Reserved
