Goodrive270 series VFD for fan and pump Basic operation guidelines
-117-
Value
Function
Description
26
DC bus voltage established
When the bus voltage is above the inverter
undervoltage, the output is valid.
27–32
Reserved
33
In speed limit
34
PROFINET communication
virtual terminal output
A signal is output based on the value set through
PROFINET communication. When the value is 1, the
ON signal is output; when the value is 0, the OFF
signal is output.
35–36
Reserved
37
Any frequency reached
38–47
Reserved
48
Fire mode activated
49
Pre-alarm of PID1 feedback
too low
50
Pre-alarm of PID1 feedback
too high
51
PID1 in sleep
52
PID2 in startup
53
PID2 stopped
54
Indication of run with
backup pressure
55
Water shortage indication of
inlet pool
56
Pre-alarm output
57
Control variable-frequency
circulation motor A
58
Control variable-frequency
circulation motor B
59
Control variable-frequency
circulation motor C
60
Control variable-frequency
circulation motor D
61
Control variable-frequency
circulation motor E
62
Control variable-frequency
circulation motor F
63
Control variable-frequency
circulation motor G
