INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-162-
Function
code
Name
Description
Default
Modify
P02.04
Rated voltage of
AM 1
0–1200V
Depends
on model
◎
P02.05
Rated current of
AM 1
0.8–6000.0A
Depends
on model
◎
P02.06
Stator resistance of
AM 1
0.001–65.535Ω
Depends
on model
○
P02.07
Rotor resistance of
AM 1
0.001–65.535Ω
Depends
on model
○
P02.08
Leakage inductance
of AM 1
0.1–6553.5mH
Depends
on model
○
P02.09
Mutual inductance
of AM 1
0.1–6553.5mH
Depends
on model
○
P02.10
No-load current of
AM 1
0.1–6553.5A
Depends
on model
○
P02.11
Magnetic saturation
coefficient 1 of iron
core of AM 1
0.0–100.0%
80.0%
○
P02.12
Magnetic saturation
coefficient 2 of iron
core of AM 1
0.0–100.0%
68.0%
○
P02.13
Magnetic saturation
coefficient 3 of iron
core of AM 1
0.0–100.0%
57.0%
○
P02.14
Magnetic saturation
coefficient 4 of iron
core of AM 1
0.0–100.0%
40.0%
○
P02.15
Rated power of
SM 1
0.1–3000.0kW
Depends
on model
◎
P02.16
Rated frequency of
SM 1
0.01Hz–P00.03(Max. output frequency)
50.00Hz
◎
P02.17
Number of pole
pairs of SM 1
1–128
2
◎
P02.18
Rated voltage of
SM 1
0–1200V
Depends
on model
◎
P02.19
Rated current of
SM 1
0.8–6000.0A
Depends
on model
◎
