INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-163-
Function
code
Name
Description
Default
Modify
P02.20
Stator resistance of
SM 1
0.001–65.535Ω
Depends
on model
○
P02.21
Direct-axis
inductance of SM 1
0.01–655.35mH
Depends
on model
○
P02.22
Quadrature-axis
inductance of SM 1
0.01–655.35mH
Depends
on model
○
P02.23
Counter-emf of
SM 1
0–10000
300
○
P02.24
Reserved
P02.25
Reserved
P02.26
Overload protection
of motor 1
0: No protection
1: Common motor protection (with low-speed
compensation). As the cooling effect of a
common motor is degraded at low speed
running, the corresponding electronic thermal
protection value needs to be adjusted properly,
the low compensation indicates lowering the
overload protection threshold of the motor
whose running frequency is lower than 30Hz.
2: Variable-frequency motor protection (without
low speed compensation). Because the heat
dissipation function for a variable-frequency
motor is not impacted by the rotation speed, it is
not necessary to adjust the protection value at
low speed running.
2
◎
P02.27
Overload protection
coefficient of
motor 1
Motor overload multiples M=Iout/(In*K)
In is rated motor current, lout is VFD output
current, K is motor overload protection
coefficient.
A smaller value of "K" indicates a bigger value of
"M".
When M=116%, protection is performed after
motor overload last for 1 hour; when M=150%,
protection is performed after motor overload
lasts for 12 minutes; when M=180%, protection
is performed after motor overload lasts for 5
minutes; when M=200%, protection is performed
100.0%
○
