INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-167-
Function
code
Name
Description
Default
Modify
8: Ethernet communication (same as the above)
9: Reserved
10: PROFINET communication
11–17: Reserved
18: Keypad (for small power models)
P03.15
Setting source of
reverse rotation
upper-limit
frequency in torque
control
0: Keypad (P03.17)
1: AI1 (100% corresponding to the max.
frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: PROFIBUS/CANopen communication (same
as the above)
8: Ethernet communication (same as the above)
9: Reserved
10: PROFINET communication
11–17: Reserved
18: Keypad (for small power models)
0
○
P03.16
Forward rotation
upper-limit
frequency set
through keypad in
torque control
Used to set the frequency upper limits. 100%
corresponds to the max. frequency. P03.16 sets
the value when P03.14=1; P03.17 sets the value
when P03.15=1.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
50.00Hz
○
P03.17
Reverse rotation
upper-limit
frequency set
through keypad in
torque control
50.00Hz
○
P03.18
Setting source of
electromotive
torque upper limit
0: Keypad (P03.20)
1: AI1 (100% corresponding to triple the motor
rated current)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen communication
0
○
