INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-194-
Function
code
Name
Description
Default
Modify
Bit 8: PID reference value (% blinking)
Bit 9: PID feedback value (% on)
Bit 10: Input terminal state
Bit 11: Output terminal state
Bit 12: Set torque (% on)
Bit 13: Pulse count value
Bit 14: Motor overload percentage (% on)
Bit 15: PLC and current step number of
multi-step speed
P07.06
Selection 2 of
parameters
displayed in running
state
0x0000–0xFFFF
Bit 0: AI1 (V on)
Bit 1: AI2 (V on)
Bit 2: AI3 (V on)
BIT3: High-speed pulse HDIA frequency
BIT4: Reserved
Bit 5: VFD overload percentage (% on)
Bit 6: Ramp frequency reference (HZ on)
Bit 7: Linear speed
Bit 8: AC incoming current
Bit 9: Upper limit frequency
Bit 10: AI0 (V on)
Bit 11–Bit 15: Reserved
0x0000
○
P07.07
Selection of
parameters
displayed in
stopped state
0x0000–0xFFFF
Bit 0: Set frequency (Hz on, slow blinking)
Bit 1: Bus voltage (V on)
Bit 2: Input terminal state
Bit 3: Output terminal state
Bit 4: PID reference value (% blinking)
Bit 5: PID feedback value (% on)
Bit 6: Set torque (% on)
Bit 7: AI1 (V on)
Bit 8: AI2 (V on)
Bit 9: AI3 (V on)
BIT10: High-speed pulse HDIA frequency
BIT11: High-speed pulse HDIB frequency
Bit 12: Count value
Bit 13: PLC and current step number of
multi-step speed
0x00FF
○
