INVT Goodrive270 Series

Goodrive270 series VFD for fan and pump Function parameter list
-234-
Function
code
Name
Description
Default
Modify
Range: -3000.0–3000.0A
P17.08
Motor power
Displays the present motor power; 100% relative
to the rated motor power. The positive value is
the motoring state while the negative value is
the generating state.
Range: -300.0–300.0% (relative to the rated
motor power)
0.0%
●
P17.09
Motor output torque
Displays the present output torque of the VFD;
100% relative to the rated motor torque. During
forward running, the positive value is the
motoring state while the negative value is
generating state. During reverse running, the
positive value is the generating state while the
negative value is the motoring state.
Range: -250.0–250.0%
0.0%
●
P17.10
Estimated motor
frequency
Displays the estimated motor rotor frequency
under the open-loop vector condition.
Range: 0.00–P00.03
0.00Hz
●
P17.11
DC bus voltage
Displays the present DC bus voltage of the VFD.
Range: 0.0–2000.0 V
0V
●
P17.12
Digital input
terminal status
Displays the present digital input terminal state
of the VFD.
0x0000–0x003F
Corresponds to HDIA, S4, S3, S2 and S1
respectively.
0x0000
●
P17.13
Digital output
terminal status
Displays the present digital output terminal state
of the VFD.
0x0000–0x000F
Corresponding to Reserved, RO1, Reserved
and Y1 respectively.
0x0000
●
P17.14
Digital adjustment
value
Displays the adjustment on the VFD through the
UP/DOWN terminal.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.15
Torque reference
value
Relative to the percentage of the rated torque of
the present motor, displaying the torque
reference.
Range: -300.0%–300.0% (of the motor rated
20.0%
●
