INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-235-
Function
code
Name
Description
Default
Modify
current)
P17.16
Linear speed
0–65535
0
●
P17.17
Reserved
P17.18
Count value
0–65535
0
●
P17.19
AI1 input voltage
Displays the AI1 input signal.
Range: 0.00–10.00V
0.00V
●
P17.20
AI2 input voltage
Displays the AI2 input signal.
Range: -10.00V–10.00V
0.00V
●
P17.21
HDIA input
frequency
Display HDIA input frequency.
Range: 0.000–50.000kHz
0.000
kHz
●
P17.22
Reserved
P17.23
PID reference value
Displays the PID reference value.
Range: -100.0–100.0%
0.0%
●
P17.24
PID feedback value
Displays the PID feedback value.
Range: -100.0–100.0%
0.0%
●
P17.25
Motor power factor
Displays the power factor of the current motor.
Range: -1.00–1.00
1.00
●
P17.26
Duration of this run
Displays the duration of this run of the VFD.
Range: 0–65535min
0m
●
P17.27
Present step of
simple PLC
Used to display the present step of the simple
PLC function.
Range: 0–15
0
●
P17.28
Motor ASR
controller output
Displays the ASR controller output value under
the vector control mode, relative to the
percentage of rated motor torque.
Range: -300.0%–300.0% (of the motor rated
current)
0.0%
●
P17.29
Pole angle of
open-loop SM
Displays the initial identification angle of SM.
Range: 0.0–360.0
0.0
●
P17.30
Phase
compensation of
SM
Displays the phase compensation of SM.
Range: -180.0–180.0
0.0
●
P17.31
High-frequency
superposition
current of SM
0.0%–200.0% (of the motor rated current)
0.0
●
P17.32
Motor flux linkage
0.0%–200.0%
0.0%
●
P17.33
Exciting current
Displays the exciting current reference value
0.0A
●
