INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-244-
Function
code
Name
Description
Default
Modify
P26.23
RO5 switch-on
delay
0.000s
○
P26.24
RO5 switch-off
delay
0.000s
○
P26.25
RO6 switch-on
delay
0.000s
○
P26.26
RO6 switch-off
delay
0.000s
○
P26.27
RO7 switch-on
delay
0.000s
○
P26.28
RO7 switch-off
delay
0.000s
○
P26.29
RO8 switch-on
delay
0.000s
○
P26.30
RO8 switch-off
delay
0.000s
○
P26.31
RO9 switch-on
delay
0.000s
○
P26.32
RO9 switch-off
delay
0.000s
○
P26.33
RO10 switch-on
delay
0.000s
○
P26.34
RO10 switch-off
delay
0.000s
○
P26.35
AO2 output
Same as the description for P06.14
0
○
P26.36
AO3 output
0
○
P26.37
Reserved
P26.38
AO2 output lower
limit
Used to define the relationship between the
output value and analog output. When the
output value exceeds the allowed range, the
output uses the lower limit or upper limit.
When the analog output is current output, 1mA
equals 0.5V.
In different cases, the corresponding analog
output of 100% of the output value is different.
0
.
0
%
○
P26.39
AO2 output
corresponding to
lower limit
0.00V
○
P26.40
AO2 output upper
limit
100.0%
○
P26.41
AO2 output
10.00V
○
