INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-53-
The keypad menu setup is shown as follows.
Level 1
Level 2
Level 3
Level 4
Common
parameter
setting
/
/
P00.10: Frequency set
through keypad
P00.00: Speed control
mode
Pxx.xx: Common
parameter setting xx
Parameter
setting
Quick setup for
function code
/
Pxx.xx
Basic parameter
group setting
P00: Basic functions
P00.xx
P07: HMI
P07.xx
P08: Enhanced functions
P08.xx
P11: Protection parameters
P11.xx
P14: Serial communication
functions
P14.xx
P99: Reserved
P99.xx
Motor parameter
group setting
P02: Motor 1 parameters
P02.xx
P12: Motor 2 parameters
P12.xx
P20: Reserved
P20.xx
P24: Reserved
P24.xx
Control
parameter group
setting
P01: Start/stop control
P01.xx
P03: Motor1 vector control
P03.xx
P04: V/F control
P04.xx
P09: PID control
P09.xx
P10: Simple PLC and
multi-step speed control
P10.xx
P13: SM control parameters
P13.xx
P21: Reserved
P21.xx
P22: Reserved
P22.xx
P23: Motor 2 vector control
P23.xx
Terminal function
group setting
P05: Input terminals
P05.xx
P06: Output terminals
P06.xx
P98: Reserved
P98.xx
Optional card
function group
setting
P15: Functions of
communication expansion card
1
P15.xx
P16: Functions of
P16.xx
