INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-83-
Function
code
Name
Description
Default
P00.00
Speed control
mode
0: Sensorless vector control (SVC) mode 0
1: Sensorless vector control (SVC) mode 1
2: Space voltage vector control mode
Note: Before using a vector control mode (0 or 1),
enable the VFD to perform motor parameter
autotuning first.
2
P03.32
Enabling torque
control
0: Disable
1: Enable
0
P03.11
Torque setting
method
0: Keypad (P03.12)
1: Keypad (P03.12)
2: AI1 (100% corresponding to triple the motor
rated current)
3: AI2
4: AI3 (same as the above)
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen communication
9: Ethernet communication
10: Reserved
11: PROFINET communication
12–17: Reserved
18: Keypad (for small power models)
Note: For setting sources 2–6, 100% corresponds
to triple the motor rated current.
0
P03.12
Torque set
through keypad
-300.0%–300.0% (of the motor rated current)
50.0%
P03.13
Torque reference
filter time
0.000–10.000s
0.010s
P03.14
Setting source of
forward rotation
upper-limit
frequency in
torque control
0: Keypad (P03.16)
1: AI1 (100% corresponding to the max. frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: PROFIBUS/CANopen communication (same as
the above)
0
