Hardware Manual
BMS Master 4 / 4.5
Ref.: IR14417 A 15.01.2018 Page 41/76
3.4.7. ENVIRONMENTAL
Operating temperature: -20°C ... +70°C (t.b.d)
Storage temperature: -40°C … +85°C
Humidity: max 95% not condensing.
At pollution level 1 the Slave C may be operated up to 1000V
At pollution level 2 the Slave C may be operated up to 650V
At pollution level 3 the Slave C must not be operated
At applications above 650 VDC non-conducting screws have to be used fixing the module
mechanically
Environmental tests:
Temperature Test ISO16750-4
o 24 h at – 40 °C
o 96 h at +85 °C
o 4 x cycle with -40°C und 85°C
Insulation Test: 300GΩ / 5kV DC
EMC: EN 55022 and EN 55024 (industrial environment)
