I+ME ACTIA BMS Master 4 - System Block Diagram

Hardware Manual
BMS Master 4 / 4.5
Ref.: IR14417 A 15.01.2018 Page 54/76
3.6.4. SYSTEM BLOCK DIAGRAM
Voltage
Temperature
Measureing
Cell Balance
Second Level
Hardware
dection
2 x Temperature
3 x Temperature
SL6_BAL-module
SL6_ANA-module
SL6_ANA-module
SL6_BAL-module
Batt.
4...12 cells
10...60V
Batt.
4...12 cells
10...60V
Sec. Level
Hardware
Configuration
2 x Temperature
3 x Temperature
Sec. Level
Hardware
Configuration
Second Level
Hardware
dection
Voltage
Temperature
Measureing
Cell Balance
To CON Modul
CPU
SPI / ISO SPI
Converter
CAN
PowerSupply
SL6_CON-module
Fail Output
(RS485)
To ANA Modul
Fail Output
(Open collector)
Master Connector
