I+ME ACTIA BMS Master 4 - Supply and Current Consumption; Environmental; Passive Cell Balance

Hardware Manual
BMS Master 4 / 4.5
Ref.: IR14417 A 15.01.2018 Page 65/76
3.6.8.6 SUPPLY AND CURRENT CONSUMPTION
The SL6 ANA is powered from the connected cells.
Description
Value
Unit
Max. Supply voltage (from the cells)
Connection CV0 - CV12
12…55
V
Max. voltage between connections (CV0 – CV1)
-0.3 … 8
V
Measurement range
5
V
Cell voltage accuracy (@3.3V)
2
mV
Current consumption (Master active)
≤ 10
mA
Current consumption (Master active max.)
≤ 20
mA
Current consumption in Standby/Sleep Mode
0.2
mA
Balance current without external Balance resistors
70…115
mA
3.6.8.7 ENVIRONMENTAL
Humidity: max. 95%, not condensing
Operating temperature: -20°C ... +70°C
Storage temperature: -40°C ... +85°C
At pollution level 2 the Slave may be operated up to 650V
At pollution level 3 the Slave must not be operated
At applications above 650 VDC non-conducting screws have to be used fixing the module
mechanically
Environmental tests:
 Temperature Test ISO16750-4:
o at – 40 °C
o 96 h at +85 °C
o 4 x cycle with -40°C und 85°C
 Insulation test: 300GΩ / 5kV DC
 EMC: EN 55022 and EN 55024 (industrial environment)
3.6.9. PASSIVE CELL BALANCE
Depending on the cell voltage, there are various slave 6 A module. The types are shown in
the following table:
Slave 6 ANA
Balance resistor
Voltage range
