CON module, 12 pole connector to BMS Master
Pin
Signal
Description
1
VNET
Power Supply from Master, typical 12VDC (9…16)
2, 8
TERM L/H
Activation CAN termination resistor 120 Ohm (short Pin 2- 8)
3, 4
CAN H
Signal CAN high, communication to Master
5, 11
FAIL A, B
Differentially error signal line RS485 to Master, only Master 4.5
(second level detection)
6
FAIL_
Static error signal to Master (second level detection)
7
GND
Ground (Minus) from Master
9, 10
CAN L
Signal CAN low, communication to Master
12
SHIELD
CON Modul, 8 pole connector for relay output
Pin
Signal
Description
1, 5
KL30 (+)
Power supply for outputs, (9 … 28V)
2, 3, 4, 8
GND
Ground (Minus)
6
SW1
Output 1
7
SW2
Output 2
CON module, 8 pole connector to 1. SL6 ANA module
Pin
Signal
Description
1, 5
T1A, T2A
Differentially ISO SPI signal to the lowest ANA module
2, 6
SHIELD
3, 7
EN-T, EN+T
Differentially stimulation signal to the lowest ANA module (ca.
10kHz)
4, 8
SI-T, SI+T
Differentially Return signal from the lowest ANA module (ca.
10kHz)
3.6.7.2 MECHANICAL DIMENSIONS
• Module size 80.5 x 97 x 17 mm;
• For mounting holes for M3-screws, symmetrically arranged in the corners, distances 67
x 83.5 mm
