I+ME ACTIA BMS Master 4 - Supply and Current Consumption; Environmentals

Hardware Manual
BMS Master 4 / 4.5
Ref.: IR14417 A 15.01.2018 Page 59/76
Attention: The mounting holes do NOT comply with the
requirements of 10 mm air and creepage distances for high
voltages.
If the slave modules are used under these conditions non-
conductive screws and/or bolts must be used.
3.6.7.3 SUPPLY AND CURRENT CONSUMPTION
The SL6_CON module must be powered from the BMS Master.
Description
Value
Unit
Voltage
9…16
V
Current (Master active)
≤ 100
mA
Current (Master active max.)
≤ 150
mA
3.6.7.4 ENVIRONMENTALS
Environmental testing:
 Temperature Test acc. ISO16750-4:
o 24 h @ – 40 °C
o 96 h @ +85 °C
o 4 x cycles at -40°C and 85°C
 Insulation test: 300GΩ / 5kV DC.
 EMC: acc. EN 55022 and EN 55024 (industrial)
