Hardware Manual
BMS Master 4 / 4.5
Ref.: IR14417 A 15.01.2018 Page 49/76
8.2 Ω and 4 V cell voltages.
When connecting external balancing resistors in applications with less than 10 cells it has to
be considered to adapt the schematics below relatively to line Z5+/Z6-. Those cells replaced
by a short connection (see 3.5.4.3) have to be removed from the schematics
