<Power> - press up/down buttons to adjust
B
<Exposure> - press up/down buttons to adjust
C
<Endpoint Mgmt> - press up/down buttons to adjust
(EpM feature is available when activated)
D
<EpM> - press to enable/disable Endpoint Management
<LM> - press to toggle Landmark patterns
E
<Rep Rate/Curve/Radius> - press up/down buttons to adjust
F
<IN> - press to adjust inner radius
<OUT> - press to adjust outer radius
