SCMA54&SCMA48
80
Parts code
Punched ID
SCMA 54 Left 8665-306-001-10 8665 C
Right 8665-306-002-10
8665 D
SCMA 48 Left 8663-306-001-10 8663 C
Right 8663-306-002-10 8663 D
e. Connect the mower deck to the lawn mower properly,
referring to the paragraph for "attaching and detaching
the mower deck" at page 68.
4. INSPECTION OF GAUGE WHEELS
As the gauge wheels are installed on the front and
rear ends of the mower, they are more vulnerable
to being hit and deformed by obstacles than any
other part. When a wheel does not turn smoothly
or is deformed, replace it with a new gauge wheel
immediately.
5. INSPECTION OF ROLLERS
Make sure that the roller turns smoothly.
(1) Roller
Important:
･ When the wheels and rollers are hard to turn,
disassemble them and clean them.
･ After re-assembly, be sure to grease them sufficiently:
6. CLEANING OF MOWER DECK
a. Remove belt cover, and clear the grass and dust
accumulated under the cover before operation,
or shorter service life of the belts and damage to
bearings and oil seals will be caused.
Caution:
Be sure to replace the removed cover after cleaning.
(1) Water hose plug
b. Pour the water into mower deck from water hose
plugs(1) and turn the blade.
c. After mowing, clear the underside of the mower deck
and blades of accumulated grass and dirt. Especially
after operation in wet grass, wash them without
fail, or accumulated wet grass and dirt will cause
performance deterioration.
Caution:
When pouring the water into mower deck to clean, be
sure to make revolution of engine low.
To Next Page
