Multi-units operation
1:OVP(rms) Over-voltage protection(rms)
2:OVP
(peak)
Over-voltage protection(peak)
3:UVP(rms) Under-voltage protection(rms)
4:OCP(rms) Over-current protection(rms)
5:OCP
(peak)
Over-current protection(peak)
6:OCP
Delay
OCP delay
7:OPP Over-power protection
8:MCL Current limiting protection
10:Range
Set
Setting value range
1:Vac-Max
2:Vac-Min
5:Freq-Max
6:Freq-Min
7:OCP-Max
8:OCP-Min
Config Config function
1:I Range Set the current measurement range.
3:On Phase Set the starting phase angle of the waveform.
4:Off Phase Set the ending phase angle of the waveform.
System System function
5:Relay Ctrl Set the relay control.
5. To test the DUT under Unbalance three-phase mode, you can connect the
communication interface (GPIB/USB/RS232/LAN/CAN/RS485) of the host A
to the PC. Please refer to 2.5 Connecting the Interface.
Set the three-phase voltage value and the angle difference of the three
phases through PC. For specific setting instructions, please refer to "IT-
M7700 Programming and Grammar Guide".
Revert to single mode
1. Press the [Link] key on the front panel of master A to cancel the three-phase
synchronization mode.
2. Set each of the three instruments to single mode.
Copyright © Itech Electronic Co., Ltd.
102
