ITech IT-M7700 Series - Page 136

Technical Specification
Parameter IT-M7723
Max. output power
1200VA
Max. output voltage
600Vac
Output phase Single-phase
Current range(rms)
12A
Current range(peak)
36A
Output frequency range
45 - 1000Hz
Phase angle degree range
0 – 359.9°
THD*1*3*6
≤0.5% at f=45~100Hz
≤1.5% at f=101~1000Hz
Crest factor 3
Line Regulation *3
≤0.06%
Load Regulation *3
≤0.15%
Output voltage *4
(VAC)
Resolution 0.1V
Accuracy *6 ±(0.2%+ 0.2% F.S.)
Frequency
Resolution 0.1Hz
Accuracy
±0.1%
Phase angle degree
range
Resolution 0.1°
Accuracy
0.5°
DC offset value 50mVdc
Efficiency 78% (Typical)
DC Output
Max. output power
1200W
Max. output voltage
±800Vdc
Maximum output current (rms)
±12A
DC voltage *4 Accuracy ±(0.2% + 0.2% F.S.)
Dynamic response time *5
≤0.5ms
Meter
AC Voltage *4
(VAC)
Range
0-600V
Resolution 0.1V
Accuracy *6 ±(0.25% + 0.25% F.S.)
AC current (rms) *4
(IAC )
Range
0.1 -12A
Resolution 10mA
