Technical Specification
Parameter IT-M7723
Accuracy *6 ±(0.25% + 0.25% F.S.)
AC current (peak)
*4(IP)
Range
0-17A
Resolution 10mA
Accuracy *6 ±(0.4% + 0.8% F.S.)
DC voltage *4
(VDC)
Accuracy ±(0.25% + 0.25% F.S.)
DC current *4(IDC ) Accuracy ±(0.25% + 0.355% F.S.)
Frequency
Range
45-1000Hz
Resolution *7 0.1Hz
Accuracy *2
±0.1%
Power *4
Resolution 100mVA
Accuracy ±(0.5% + 0.5% F.S.)
Other
Protection
OTP, OCP, OVP, OPP
Interface
GPIB, USBTMC, LAN, RS232, RS485
Dimension
(WxHxD)
Without foot post,
protective cover
680 × 436 × 44 mm
With foot post, pro-
tective cover
730 × 457 × 57 mm
Weight
12KG
*1: Min voltage for THD test is 100Vac.
*2: Min voltage for frequency display accuracy is 100Vac.
*3: Tested with pure resistive load.
*4： F.S. value is full range.
*5： From 10% to 90% full load.
*6: For specifications above 800Hz, multiply by 1.2.
*7: The applicable range of frequency resolution is 45~99.9Hz.
Copyright © Itech Electronic Co., Ltd.
126
