ITech IT-M7700 Series User Manual

Operation and Application
Ext IO1 Parameter setting for IO1.
Off Turn off the IO1 function.
Output Config IO1 as output pin.
L if out on When the output state of the instru-
ment is On, this pin outputs 0V.
When the output state of the instru-
ment is Off, this pin outputs 5V.
H if out on When the output state of the instru-
ment is On, this pin outputs 5V.
When the output state of the instru-
ment is Off, this pin outputs 0V.
Input Config IO1 as input pin.
L To out on When send 0V signal to IO1, the in-
strument turns on the output. When
send 5V signal to IO1, the instrument
turns off the output.
H To out on When send 5V signal to IO1, the in-
strument turns on the output. When
send 0V signal to IO1, the instrument
turns off the output.
Ext IO2 Parameter setting for IO2.
Off Turn off the IO2 function.
Output Config IO2 as output pin.
L if out on When the output state of the instru-
ment is On, this pin outputs 0V.
When the output state of the instru-
ment is Off, this pin outputs 5V.
H if out on When the output state of the instru-
ment is On, this pin outputs 5V.
When the output state of the instru-
ment is Off, this pin outputs 0V.
Input Config IO2 as input pin.
L To out on When send 0V signal to IO2, the in-
strument turns on the output. When
send 5V signal to IO2, the instrument
turns off the output.
H To out on When send 5V signal to IO2, the in-
strument turns on the output. When
send 0V signal to IO2, the instrument
turns off the output.
Off Timer Set the output timer function.
Off Turn the output timer off.
On Turn the output timer on.
Copyright © Itech Electronic Co., Ltd.
60
