ITech IT-M7700 Series User Manual

Operation and Application
Timer Set the output time.
Table 4–2 IT-M7723 menu
Function Function menu
List Mode List mode
Off Turn the list function off.
1~5 Turn List 1~5 on.
List
Trigger
Set the trigger mode to run the List.
Off After the Trigger key is pressed, the instrument will au-
tomatically run the real-time List file.
On After the Trigger key is pressed, the instrument will run
the realtime List file in single step.
Dimmer Dimmer Function. (only displayed under the AC Mode)
Off Turn the dimmer function off.
LeadingEdge Enable the Leading Edge Dimmer function.
Dimmer Phase Set the leading edge dimmer phase
angle.
TrailingEdge Enable the Trailing Edge Dimmer function.
Dimmer Phase Set the trailing edge dimmer phase
angle.
Surge
Trap
Surge/trap function.
Off Turn the surge/trap function off.
On Turn the surge/trap function on.
Period Set the period of the surge/trap.
Width Set the surge/trap width.
Percent Set the percentage of the surge/ trap
amplitude to AC signal amplitude
(rms).
Ext IO1 Parameter setting for IO1.
Off Turn off the IO1 function.
Output Config IO1 as output pin.
L if out on When the output state of the instru-
ment is On, this pin outputs 0V.
When the output state of the instru-
ment is Off, this pin outputs 5V.
