Command Reference Epic 950 OEM Integration Manual
95-05245 Rev G Page 113
GS $ – Set Absolute Vertical Position in Page Mode
Description
Sets the vertical print position measured from the top of the page, for the currently
selected print direction. Distance is specified in dots, where 1 dot = 1/203 inch.
The n1 and n2 parameters are evaluated to form a 16-bit word as follows: first, the n1
parameter’s decimal value is multiplied by 256, then the result is added to the decimal
value of the n2 parameter.
Expression
ASCII [GS] $ <n1><n2>
Hexadecimal 1DH 24H <n1><n2>
Decimal <29> <36> <n1><n2>
Parameters n1 = most significant byte of start position
n2 = least significant byte of start position
