Ithaca Epic 950 - Top-of-Form;Ticket Out Sensor; Ticket Taken Sensor; Chassis Open Sensor;Audible Alarm; Printer Status LED

Epic 950 Specifications and Requirements Epic 950 OEM Integration Manual
Page 16 Rev G 95-05245
# of Characters: 6 min./18 max.
Symbol Contrast Value: 70% min.
Applicable Standards: ANSI X3.182
gsa-p0038.001.01
Design Envelope: Ticket Clearance
A minimum paper clearance distance of .75" is required above the printer’s ticket
buckets. The minimum clearance for all ticket buckets will vary, but should fall within the
.75" minimum clearance measurement.
.75
Figure 5. Design Envelope: Ticket Clearance
