Command Reference Epic 950 OEM Integration Manual
Page 132 Rev G 95-05245
GS l – Draw Line in Landscape Mode
Description
The GS l (lower-case “L”) command draws a line in landscape mode. The thickness of
the line is determined by the bit set by the parameter m.
Expression
ASCII [GS] l <n1> <n2> <L1> <L2> <m>
Hexadecimal 1DH 6CH <n1> <n2> <L1> <L2> <m>
Decimal <29> <108> <n1> <n2> <L1> <L2> <m>
Parameters n1 = most significant byte of the offset from the left (in dots)
n2 = least significant byte of the offset from the left (in dots)
L1 = most significant byte of the line length (in dots)
L2 = least significant byte of the line length (in dots)
where
offset = inches/203 = (n1 * 256) + n2
length = inches/203 = (L1 * 256) + L2
m = the data (where 0 = top and 7 = bottom)
