Operational Procedures Epic 950 OEM Integration Manual
Page 46 Rev G 95-05245
• Align the base of the Inner Chassis with the outer walls of the Outer Chassis,
seating it within side walls A and B as shown in Figure 17.
• While pulling outwards on the Release Lever, slide the Inner Chassis towards the
rear of the Outer Chassis until it latches at the rear of the Outer Chassis.
