ITT HYDROVAR Series User Manual

14
5 Technical Data
HYDROVAR Power Supply
Type Rated
output
Voltage limits
48-62 Hz
Rated current
input
Recommended
line protection
Maximum
connection
HV [kW] [V] [A] [A] [mm²]
2.015 1,5 14,0 20
2.022 2,2
1~230 ± 15%
20,0 25
10
4.022 2,2 7,6 13
4.030 3 9,1 13
4.040 4
3~380-460 ± 15%
11,4 16
10
4.055 5,5 15,1 20
4.075 7,5 19,6 25
4.110 11
3~380-460 ± 15%
27,8 32
10
HYDROVAR Output to the motor
Type Rated
Output
Max. Voltage Output Rated Current
output
Motor connection cables
HV [kW] [V] [A] mm²
2.015 1,5 7
2.022 2,2
3~ U
in
10
4x1,5 – 4x4
4.022 2,2 5,7
4.030 3 7,3
4.040 4
3~ U
in
9
4x1,5 – 4x4
4.055 5,5 13,5
4.075 7,5 17
4.110 11
3~ U
in
23
4x2,5 – 4x6
Make sure that the HYDROVAR’s electrical data match those of the electric
pump. Improper combinations may cause malfunctions and fail to ensure the
protection of the electric motor.
The rated current of the motor must be lower than the rated current of the HYDROVAR
to prevent overheating or shutdown due to “OVERLOAD”.
The max. output current of the HYDROVAR could reach 110% of the nominal current for
max. 60 sec. before the error “OVERLOAD” will occur.
