ITT HYDROVAR Series User Manual

86
1000
1000 SUBMENU
TEST RUN
1005
1005 TEST RUN
after 100 hrs
Automatic test run
Possible settings: OFF – 100 h.
The Automatic Test Run starts up the pump at the set time after the last stop to prevent
the pump from blocking.
Test Run Time, Frequency and Boost could be chosen in the parameters below.
For deactivating the automatic test run press ▼ until “OFF” appears on the display.
The test run is only active, when the pump is stopped but External ON/OFF contact
(X3/7-8) is closed and even pump is manually released!
1010
1010 TESTRUN FRQ.
30.0 Hz
Frequency for manual and automatic test run
Possible settings: 0 – Fmax
1015
1015 TESTR. BOOST
10.0 %.
Setting of the motor starting voltage in % of rated
input voltage
Possible settings: 0 – 25% of maximum input voltage is possible
1020
1020 TESTR. TIME
5 sec
Test Run time
Possible settings: 0-180 sec.
1025
1025 SEL. DEVICE
01
Select Inverter for manual testrun
Possible settings: 01-08
1030
1030 TESTRUN MAN
Press ► 3 sec.
Manual Test Run, Confirm test run for selected unit
With this parameter it is possible to ensure a manual Test Run only for a selected unit.
(Even fixed speed pumps in Cascade Relay Mode could be activated)
By pressing
► button for approx. 3 sec. a test run will be started.
