6 Dimensions and Weights

HV 2.015 / 2.022

HV 4.022 / 4.030 / 4.040

All dimensions in millimetres! Drawings are not in scale!

Lifting aids must have the proper dimensions.

Type Weight [kg]

Basic

Master/

Single

HV 2.015

HV 2.022

HV 4.022

HV 4.030

HV 4.040

4,00 4,40

a … minimum centre-distance between the HYDROVAR 300 [mm]

b … expansion space for maintenance 110 [mm]
