ITT HYDROVAR Series User Manual

79
0700
0700 SUBMENU
OUTPUTS
0705
0705 ANALOG OUT1
Output Frequency
Analogue Output 1
Analogue output 0 – 10V = 0 - 100% Terminal: X3/20
Possible settings: - Actual value For wiring see chapter 9.4.4!
- Output frequency (0 - fmax)
0710
0710 ANALOG OUT2
Actual value
Analogue Output 2
Possible settings: Actual Value, Output frequency
Analogue output 4 – 20mA = 0 - 100% Terminal: X3/21
Possible settings: - Actual value For wiring see chapter 9.4.4!
- Output frequenc (0 - fmax)
Both Status-Relays can be used to indicate the current status and fault condition of the
HYDROVAR. For wiring see chapter 10.3.4.
0715
0715 CONF REL 1
Running
Configuration of the Status Relay 1 (X5/1-2-3)
0720
0720 CONF. REL 2
Errors
Configuration of the Status Relay 2 (X5/4-5-6)
Possible settings: Power, Errors, Warnings, StandBy, Errorreset
Config. Explanation Action
Power HYDROVAR is connected to power supply
Relay1: X5/ 1-3 closed
Relay2: X5/ 4-6 closed
Running Motor is running
Relay1: X5/ 1-3 closed
Relay2: X5/ 4-6 closed
Errors An error is indicated on the HYDROVAR
Relay1: X5/ 1-3 closed
Relay2: X5/ 4-6 closed
Warnings A warning is indicated on the HYDROVAR
Relay1: X5/ 1-3 closed
Relay2: X5/ 4-6 closed
StandBy
Pump is released manually and by external release, no
error/warning is indicated and HYDROVAR doesn’t run
Relay1: X5/ 1-3 closed
Relay2: X5/ 4-6 closed
Errorreset
If Parameter ERRORRESET [0615] is activated and a
Warning occurs 5 times -> Error ->
Relay1: X5/ 1-3 closed
Relay2: X5/ 4-6 closed
