54
20
20 SUBMENU
STATUS
Status of all units in a pump group
Using this submenu it is possible to check the status (including failures and motor hours) of
all connected units.
21
21 STATUS UNITs
00000000
Status of all Units
This parameter gives a quick overview beyond the status of the connected units
- In Cascade Serial mode the status of all (max. 8) connected units is shown (whereas
1=activated / 0=deactivated)
- In Cascade Relay mode (Master is fitted with additional relay card) the status of the
5 Relay- switching contacts is shown.
e.g. Mode – Cascade Serial
21 STATUS UNITs
11001000
Unit 1, 2 and 5 are running
e.g. Mode – Cascade Relay
21 STATUS UNITs
10100 - - -
Relay Contact 1 and 3 are closed
22
22 SELECT DEVICE
* 1 *
Select device
Possible settings: 01-08
If you would like to check the following parameters which show the current status, the
motor hours and the last failures which occurred, you have to select the desired unit which
should be checked.
Regarding to the selected MODE [0105] the desired unit can be chosen:
Mode CASCADE SERIAL:
The number of the device depends to the pre-selected Address.
e.g. Device 01 -> Master Inverter with pre-selected Address 1
Device 02 -> Basic Inverter with pre-selected Address 2
Device 03 -> Basic Inverter with pre-selected Address 3
For selecting desired address on a Basic Inverter, see chapter 9.4.3.2 Addressing.
To set the address on a Master Inverter, see Submenu 1200 RS485-Interface.
