10.4 Software Parameters
In the following chapters all available parameters of the secondary menu are listed.
On the Index window there is shown the factory setting and in the line below the
possible settings.
The general parameter description is written for the HYDROVAR Master Inverter (Full
featured HYDROVAR including the high level control card which supports also the optional
modules like the optional “Relay Card” and all special software features).
When using a HYDROVAR Single Inverter (HYDROVAR with control card developed only
for single pump operation) there are less software features in comparison to the
HYDROVAR Master Inverter. All Parameters which are not active for a HYDROVAR Single
Inverter are marked with the following Symbol:
……. Parameter not available for a HYDROVAR Single Inverter
NOTICE! All changes will be saved automatically in case of a disconnection of the
power supply!
00
00 MAIN MENU
The 1
st
Window, REQUIRED VALUE [02] and EFFECTIVE REQUIRED VALUE [03] depend on
the selected mode which has been chosen with parameter MODE [0105]. The difference
between the windows in the different modes is shown below:
a) Active MODE [0105] = Controller (Default setting)
ITT XX.X Hz
STOP X.XX Bar
1
st
display at Mode Controller
This window shows the status of the HYDROVAR.
ON Manually and external released
Stop of the HYDROVAR by pressing ▼
STOP Manually stopped
Start of the HYDROVAR by pressing ▲
OFF External release (X3/7-8) is open
To start up the HYDROVAR close external
release or bridge terminal X3/7-8
S
