8.3 Assemble Instruction
HV 2.015 – HV 4.110
Display
Pressure transmitter
Motor conduit box
4 Mountin
g
clam
p
s
Centre bit
4 Screws
M5x60
Motorcable
HYDROVAR - cover
4
screws (to fix the cover)
PTC
Motor fan cover
Motor
