68
0300
0300 SUBMENU
REGULATION
0305
0305 JOG 0.0Hz
X.XX Bar
Both current output frequency and actual value are
shown.
• By pressing ▲ or ▼ in this menu, the internal controller of the HYDROVAR will be shut
off and the inverter changes to manual mode.
• With the ▲ and ▼ buttons any constant speed can be set without influence of the
actual value of the control signal!
• If this value becomes 0.00 Hz the HYDROVAR stops.
• As soon as the window will be left by pressing ◄ or ►, the HYDROVAR restart normal
mode.
0310
0310 WINDOW
10 %
Regulation Window
Possible settings: 0 – 100% of required value
• Determines the band, where the slow Ramp changes to the fast Ramp
o for steep pump-curves and closed loop systems ~20-30%
0315
0315 HYSTERESIS
80%
Ramp Hysteresis
Possible settings: 0 – 100%
• Determines the band, where the normal Regulation is done
(Change between the slow Ramps)
• for an accurate controlling (without automatic shut-off) ~99%, e.g. constant flow
control
0320
0320 REG. MODE
normal
Regulation mode
Possible settings: normal, invers
Normal: Speed is increased with falling actual value signals. (e.g.: Control at constant
output pressure)
Inverse: Speed is reduced with falling actual value signal. (e.g.: Control at constant suction
pressure or at constant level on the suction side)
