70
0400
0400 SUBMENU
SENSOR
Within this submenu all sensors which are connected to the HYDROVAR can be configured.
(Either two transducers with current signal input or voltage signal input)
It isn’t possible to install two different transducer types because configurations are the
same for all connected sensors.
Connection of the Sensors: See chapter 9.4.4.1
0405
0405 DIMENS. UNIT
Bar
Dimension Unit
Possible settings: bar, psi, m
3
/h, g/min, mH2O, ft, °C, °F, l/sec, l/min, m/sec, …, %
Chose the desired Dimension Unit by pressing or .
By changing the DIMENSION UNIT, you have to consider to change the SENSOR RANGE
[0420] according to the new DIMENSION UNIT too!
0410
0410 CONF SENSOR
Sensor 1
Selection of the Sensor
Possible settings: - Sensor 1 - Sensor 2 - Auto
- Switch Dig1 - Switch Dig2 - Switch Dig3 - Switch Dig4
- Auto Lower - Auto Higher - Sensor 1 – Sensor 2
This parameter determines how the connected sensors are used and which one is active.
It is also possible to measure the difference of two connected sensors or to configure an
automatic switch over in case of a faulty sensor.
Sensor 1
Sensor 1is constantly active.
0/4-20mA Signal ……. connected to X3/2 and X3/3 (+24V)
0-10V Signal ……. connected to X3/6 and X3/3 (+24V)
Sensor 2
Sensor 2is constantly active.
0/4-20mA Signal ……. connected to X3/4 and X3/3 (+24V)
0-10V Signal ……. connected to X3/5 and X3/3 (+24V)
Auto Automatic switch over in case of a faulty transmitter.
Switch Dig1 Manual switching by closing Digital Input 1 (X3/9-10)
Switch Dig2 Manual switching by closing Digital Input 2 (X3/6-GND)
Switch Dig3 Manual switching by closing Digital Input 3 (X3/5-GND)
Switch Dig4 Manual switching by closing Digital Input 4 (X3/15-GND)
Auto Lower
The sensor with the lower actual value (or available sensor in case of a
faulty sensor) is used automatically
Auto Higher
The sensor with the higher actual value (or available sensor in case of a
faulty sensor) is used automatically
Sens.1 – Sens.2 The difference of both connected sensors is taken as actual value
S
