janitza UMG 503 - Table 1 a: Measured Values (Floating Point); Current, Voltage, and Power Values; Harmonic and EMAX Values

Page 75= Key 1 = Key 2 = Key 3 = Maximum or consumption = Minimum or supply
Table 1a
Measured values in floating point format
Description Index Address(dez) r/w
1)
Type Unit Comment
DPV1 DPV0/MODB.
Current 64 1000 r meas. val.
2)
A L1, L2, L3
Voltage N-L 65 1012 r meas. val.
2)
V L1, L2, L3
Voltage L-L 66 1024 r meas. val.
2)
V L1-L2, L2-L3, L1-L3
Real power 67 1036 r meas. val.
2)
W Sign -=Supply, +=Consumption
Apparent power 68 1048 r meas. val.
2)
VA L1, L2, L3
Reactive power 69 1060 r meas. val.
2)
var Sign -=cap, +=ind
cos(phi) 70 1072 r meas. val.
2)
Sign -=cap, +=ind
Frequency 71 1084 r meas. val.
2)
Hz L1, L2, L3
Real power, sum 72 1096 r sum
3)
W Sign -=Supply, +=Consumption
Apparent power, sum 1100 r sum
3)
VA
Reactive power, sum 1104 r sum
3)
var Sign -=cap, +=ind
cos(phi), sum 73 1108 r sum
3)
Sign -=cap, +=ind
Total harmonic distortion _U
Measured value 1112 r float[3] % L1, L2, L3
Maximum value 1115 r float[3] % L1, L2, L3
Total harmonic distortion _I
Measured value 1118 r float[3] % L1, L2, L3
74 1120
Maximum value 1121 r float[3] % L1, L2, L3
Partial harmonics _U
Maximum value 1124 r float[20][3] V Partial harmonics 1-20; L1, L2, L3
75 1132
.. ..
79 1180
Partial harmonics _U
Measured value 1184 r float[20][3] V Partial harmonics 1-20; L1, L2, L3
80 1192
.. ..
84 1240
Partial harmonic _I
Maximum value 1244 r float[20][3] A Partial harmonics 1-20; L1, L2, L3
85 1252
.. ..
89 1300
Partial harmonic _I
Measured value 1304 r float[20][3] A Partial harmonic 1-20; L1, L2, L3
90 1312
.. ..
94 1360
Real power EMAX 1365 r float W Sign -=Supply, +=Consumption
95 1372
96 1384
1)
r/w = read/write
2)
measured value {float: measured value[L1-L3], mean value[L1-L3], lowest value[L1-L3], peak value[L1-L3]}
3)
sum {float: measured value, mean value, lowest value, peak value}
