janitza UMG 503 - Table 1 b: Measured Values (Floating Point); Harmonic Distortion and Current Values

Page 76 = Key 1 = Key 2 = Key 3= Maximum or consumption = Minimum or supply.
Table 1b
Measured values in floating point format
Description Index Address(dez) r/w
1)
Type Unit Comment
DPV1 DPV0/MODB.
Total harmonic distortion _U
Mean value 1390 r float[3] % L1, L2, L3
Total harmonic distortion _I
Mean value 1393 r float[3] % L1, L2, L3
97 1396
Partial harmonics _U
Minimum value 1400 r float[20][3] V Partial harmonic 1-20; L1, L2, L3
98 1408
.. ..
102 1456
Partial harmonics _I
Minimum value 1460 r float[20][3] A Partial harmonic 1-20; L1, L2, L3
103 1468
.. ..
107 1516
Partial harmonics _U
Mean value 1520 r float[20][3] V Partial harmonic 1-20; L1, L2, L3
108 1528
.. ..
112 1576
Partial harmonics _I
Mean value 1580 r float[20][3] A Partial harmonic 1-20; L1, L2, L3
113 1588
.. ..
117 1636
Total harmonic distortion _U
Minimum value 1640 r float[3] % L1, L2, L3
Total harmonic distortion _I
Minimum value 1643 r float[3] % L1, L2, L3
Current, N 1646 r float A
118 1648
119 1660
Maximum of current mean value 1663 r float[3] A L1, L2, L3
