janitza UMG 503 - Table 2: Energy (Floating Point); Real and Reactive Energy Values

Page 77= Key 1 = Key 2 = Key 3 = Maximum or consumption = Minimum or supply
Table 2
Energy in floating point format
Description Index Address(dez) r/w
1)
Type Unit Comment
DPV1 DPV0/MODB.
Real energy, Consumption 220 2000 r double[4] Wh Energy, Tariff1, Tariff2, Tariff3, Tariff4
Reactive energy, inductive 221 2010 r double[4] varh Energy, Tariff1, Tariff2, Tariff3, Tariff4
Reactive energy, capacitive 222 2020 r double[4] varh Energy, Tariff1, Tariff2, Tariff3, Tariff4
Real energy, supply 223 2030 r double[4] Wh Energy, Tariff1, Tariff2, Tariff3, Tariff4
Reactive energy
without rev. running stop 224 2040 r double[4] varh Energy, Tariff1, Tariff2, Tariff3, Tariff4
Real energy
without rev. running stop 225 2050 r double[4] Wh Energy, Tariff1, Tariff2, Tariff3, Tariff4
